Specification

General Features:

Device Type: ADSL2+ Modem Router

Wireless Speed: Up to 300Mbps

Standards: IEEE 802.11b/g/n, ITU-T G.992.5 (ADSL2+), ITU-T G.992.3 (ADSL2), ITU-T G.992.1 (ADSL)

Antenna: 2 x 5dBi fixed omnidirectional antennas

Buttons: WPS/Reset Button, Wireless On/Off Button, Power On/Off Button

LED Indicators: Power, ADSL, Internet, LAN (1-4), WLAN, WPS

Hardware Specifications:

LAN Ports: 4 x 10/100Mbps RJ45 ports

WAN Port: 1 x RJ11 for ADSL connection

Processor: Integrated chipset

Power Supply: External 9V DC / 0.85A

Wireless Features:

Frequency: 2.4GHz

Wireless Security: WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryption

Wireless Modes: Access Point, Wireless Router

WDS Bridging: Supported

Channel Bandwidth: 20/40MHz

ADSL Features:

ADSL Standards: ADSL, ADSL2, ADSL2+

Annex: Annex A/L/M

Downstream Rate: Up to 24Mbps

Upstream Rate: Up to 3.5Mbps

Software Features:

QoS (Quality of Service): ATM QoS, Traffic Prioritization

Firewall Security: NAT Firewall, SPI Firewall, MAC/IP/URL Filtering

VPN Pass-through: PPTP, L2TP, IPSec

DHCP: Server, Client, Address Reservation

Port Forwarding: Virtual Server, DMZ, UPnP

Management: Web-based Interface, TR-069, SNMP v1/2c

Other Features:

Operating Temperature: 0°C–40°C

Storage Temperature: -40°C–70°C

Operating Humidity: 10%–90% non-condensing

Storage Humidity: 5%–90% non-condensing

Description

The TP-LINK TD-W8961ND 300 MBPS ROUTER compiles of ADSL 2/2+ Modem, Wireless N Access Point, and 4-Port Router, in a single device. Its 300 Mbps wireless transmission rate is ideal for both bandwidth-sensitive tasks and basic work& nbsp. The Easy Setup Assistant of TP-LINK TD-W8961ND with multi-language support provides quick &. In addition, provides an easy installation process. One-touch wireless security encryption with the"WPS" button and Wi-Fi On/Off button made it easy for the users to operate in the shortest possible time. Again, its multiple air vents of it, guarantee system stability and ensure high operating performance. Besides, Guest Network provides separate access for guests while securing the Home Network.
