Specification

The TP-Link Archer GX90 is an AX6600 Tri-Band Wi-Fi 6 gaming router designed to deliver high-speed connectivity and advanced features tailored for gaming enthusiasts.

Wireless Standards and Speeds:

Wi-Fi Standards: IEEE 802.11ax/ac/n/a for 5 GHz; IEEE 802.11ax/n/b/g for 2.4 GHz.

Tri-Band Speeds: Combined speeds up to 6579 Mbps:

5 GHz (Gaming Band): 4804 Mbps (802.11ax, HE160)

5 GHz: 1201 Mbps (802.11ax)

2.4 GHz: 574 Mbps (802.11ax)

Hardware Specifications:

Processor: 1.5 GHz Quad-Core CPU

Antennas: 8 detachable high-performance antennas

Ethernet Ports:

1× 2.5 Gbps WAN/LAN Port

1× Gigabit WAN/LAN Port

3× Gigabit LAN Ports

USB Ports:

1× USB 3.0 Port

1× USB 2.0 Port

Game Band: Dedicated 4.8 Gbps band exclusively for gaming devices, ensuring minimal interference and optimal performance.

Game Accelerator: Automatically detects and optimizes gaming streams to maintain immersive gameplay.

Game Statistics: Provides real-time metrics such as latency, game duration, and network resource allocation through a user-friendly interface.

Game Protector: Enhanced HomeCare™ security system offering malicious site checker, port intrusion prevention, and infected device isolation.

Expansive Coverage: Combines 8 antennas, Beamforming, high-power FEM, and 4T4R technologies to deliver Wi-Fi coverage suitable for up to a 4-bedroom house.

2.5 Gbps Wired Connection: Equipped with a 2.5 Gbps WAN/LAN port to maximize high-speed internet connections.

Powerful Processing: The 1.5 GHz Quad-Core CPU ensures peak network performance.

Easy Setup: Can be set up in minutes using the TP-Link Tether app.

Security and Software:

Wi-Fi Encryption: Supports WPA, WPA2, WPA3, and WPA/WPA2-Enterprise (802.1x).

Network Security: Features SPI Firewall, Access Control, IP & MAC Binding, and Application Layer Gateway.

Guest Network: Offers separate guest networks on both 2.4 GHz and 5 GHz bands.

VPN Support: Compatible with OpenVPN and PPTP protocols.

OneMesh™ Support: Allows for seamless whole-home coverage when used with other TP-Link OneMesh™ products.

Physical Dimensions:

Size: 8.3 × 8.3 × 2.0 inches (212 × 212 × 51.8 mm)

Manufacturer warranty

Warranty: 1 Year

Description

The TP-Link Archer GX90 comes with a Tri-Band structure that provides a 4.8 Gbps Game Band exclusive for your gaming rigs and bings pure immersion. It comes with a 1.5 GHz Quad-Core CPU and 3 coprocessors to ensure your network performance is always at peak run. It features OFDMA technology that increases capacity by 4 times to enable simultaneous transmission to more devices. The TP-Link Archer GX90 comes with eight high-gain external antennas and Beamforming technology combined to extend strong, reliable Wi-Fi throughout your home. Beamforming technology detects devices and concentrates wireless signal strength towards them, especially for previously hard-to-reach outlets. Enjoy smooth gaming, video streaming, and live feed simultaneously. OFDMA makes your WiFi stronger by allowing multiple clients to share one band at the same time, which cuts latency and jittering. It is equipped with an advanced Qualcomm chipset and high memory. You can enjoy fast connections with minimal latency even under a heavy load of transmission. Every click for website links and online playback on your laptop and phone just responds quicker. The TP-Link Archer GX90 comes with a 1-year warranty.
