Key Features
Model: DS9208
Weight: 9.5 oz./269 g
Color: Midnight Black
Operating Temp: 32° F to 104° F / 0° to 40° C
Specification
|
Dimensions |
5.512
in. H x 3.232 in. W x 3.150 in. D<br>14.0 cm H x 8.21 cm W x 8.0 cm D |
|
Weight |
9.5
oz./269 g |
|
Voltage
and Current |
Idle:
5 ± 10% VDC @ 150ma average<br>Scanning: 5 ± 10% VDC @ 230ma average |
|
Color |
Midnight
Black |
|
1-D
Barcodes Supported |
UPC/EAN
(UPCA/UPCE/UPCE1/EAN-8/EAN-13/JAN-8/JAN-13 plus supplementals, |
|
PDF417
(and variants) |
PDF417
(Standard, Macro), MicroPDF417(Standard, Macro), Composite Codes (CC-A, CC-B,
CC-C) |
|
2-D
Barcodes Supported |
TLC-39,
Aztec (Standard, Inverse), MaxiCode, DataMatrix/ECC 200 (Standard, Inverse),
QR Code (Standard, Inverse, Micro) |
|
Postal
Barcodes Supported |
U.S.
Postnet and Planet, U.K. Post, Japan Post, Australian Post, |
|
Operating
Temperature |
32°
F to 104° F / 0° to 40° C |
|
Humidity |
5%
to 85% RH (non-condensing) |
|
Drop
Specification |
Withstands
multiple 5 ft./1.5 m drops to concrete |
|
Ambient
Light Immunity |
Immune
to natural and artificial ambient light (i.e. sunlight, incandescent,
fluorescent, mercury vapor, sodium vapor) |
|
Electronic
Article Surveillance |
Compatible
with Checkpoint EAS deactivation systems |
|
Accessories |
Wall
mount bracket; locking mount bracket |
|
Light
Source |
Aiming
pattern: single dot, 625nm LED<br>Illumination: 630nm LEDs |
|
Imager
Field of View |
46°
Horizontal x 29.5° Vertical |
|
RollPitchYaw |
360°±
65°± 60° |
|
Print
Contrast |
25%
minimum reflective difference |
|
Swipe
Speed (Vertical Read Rate) |
Up
to 90 in./2.3 m per second |
|
Graphics
Format Support |
Images
can be exported as Bitmap, JPEG, or TIFF |
|
Transfer Speed |
USB
2.0: Up to 12 Megabits/second<br>RS-232: Up to 115 kb/second |
|
Transfer Time |
A
typical USB application is |
