Key
Features
Model:
VIGI C230 (4mm)
Sensor: 1/2.8” Progressive Scan CMOS
Resolution:
Max. 3 MP (2304 × 1296) at 25/30 fps.
Lens:
4mm, Aperture: F1.6, IR Distance: 30 meters
Features:
PoE, IP67, IK10, Microphone, 3D DNR, Smart Detection
Specification
The TP-Link VIGI C230 is
a 3MP Full-Color Dome Network Camera equipped with a 4mm fixed focal lens.
Camera:
Image Sensor: 1/2.8”
Progressive Scan CMOS
Shutter Speed: 1/3 to
1/10000 seconds
Slow Shutter: Supported
Minimum Illumination:
Color: 0.005 Lux; 0 Lux with IR/White Light
Day/Night Mechanism: IR
Cut Filter
Day/Night Switch:
Unified/Scheduled/Auto
Lens:
Type: Fixed Focal Lens
Focal Length: 4 mm
Aperture: F1.6
Field of View (FOV):
Horizontal: 89.1°
Vertical: 45.1°
Diagonal: 106.9°
Lens Mount: M12
DORI Distance:
Detect: 70 m (230 ft)
Observe: 29 m (96 ft)
Recognize: 14 m (46 ft)
Identify: 7 m (23 ft)
Angle Adjustment
(Manual):
Pan: 0° to 355°
Tilt: 0° to 75°
Illuminator:
IR LED:
Quantity: 1
Range: 30 m
Wavelength: 850 nm
White LED:
Quantity: 1
Range: 30 m
Illuminator On/Off
Control: Auto/Scheduled/Always on/Always off
Video:
Max. Resolution: 2304 ×
1296
Main Stream:
Frame Rate: 1 fps, 5
fps, 10 fps, 15 fps, 20 fps, 25 fps
Resolution Options:
2304x1296, 2048x1280, 1920x1080, 1280x720
Sub-Stream:
Frame Rate: 1 fps, 5
fps, 10 fps, 15 fps, 20 fps, 25 fps
Resolution Options:
704x576, 640x480, 352x288, 320x240
Bit Rate Control: CBR,
VBR
Video Compression:
Main Stream: H.265+/H.265/H.264+/H.264
Sub-Stream: H.265/H.264
Video Bit Rate:
Main Stream: 256 Kbps to
4 Mbps
Sub-Stream: 64 Kbps to
512 Kbps
Image Settings: Mirror,
Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance,
Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software,
Rotation (90°/270°)
Image Enhancement:
BLC/3D DNR/HLC/SmartIR
Wide Dynamic Range: DWDR
SNR: ≥ 52 dB
Image Parameters Switch:
Yes
Privacy Mask: Up to 4
Masks
ROI: 1 Region
OSD Setting: Yes
Audio:
Audio Communication: N/A
Audio Input: Yes
Audio Output: N/A
Audio Compression: Yes
Audio Sampling Rate: 8
KHz
Environment Noise
Filtering: Yes
Audio Bit Rate: 64 Kbps
(G.711 alaw)
Network:
Protocol: TCP/IP, UDP,
ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP, UDP, SSL/TLS
ONVIF: Yes
API: ONVIF
Simultaneous Live View:
3 Main Streams & 3 Sub-Streams
Client: VIGI App, VIGI
Security Manager, VIGI NVR, Web
Web Browser
Compatibility: Google Chrome® 57 and above, Firefox® 52 and above, Safari® 11
and above, Microsoft® Edge 91 and above
Cloud Support: Yes
General:
Operating Temperature:
-30–60 °C
Storage Temperature:
-40–60 °C
Operating Humidity: 95%
or Less (Non-Condensing)
Warranty
Warranty: 1 Year
Description
The
TP-Link VIGI C230 3MP Full-Color Audio Dome IP Camera obtains 24-hour color
details, even in pitch-black conditions. With its large-aperture lens,
high-sensitivity sensor, and attached supplemental lights. The camera has 3 MP
and more than enough pixels to pick up some of the more discrete details. The
TP-Link VIGI C230 3MP Dome IP Camera features a built-in microphone to record
anything going on within a 15-ft radius of the camera. Receive notifications
and check feeds when someone crosses a boundary, enters an area you've set,
obstructs the camera, or removes or abandons objects. Without using any extra
bandwidth, your TP-Link VIGI C230 3MP Full-Color Audio Dome IP Camera transmits
compressed, crystal-clear video to save disk space, ease network loads, and
reduce monitoring costs without sacrificing image quality. With the help of
expert technologies like Smart IR, WDR, 3D DNR, and Night Vision, VIGI can
process videos to significantly increase their quality—a crucial aspect of your
monitoring. Not only do two power supply types increase your convenience, but
they also make wiring surprisingly simple. This VIGI dome camera is constructed
robustly to survive vandalism and hard settings with rain and dust for constant
security anywhere and anytime. It has a durable casing that is resistant to
vandalism and a waterproof design. Using the web UI, NVR UI, VIGI app, and VIGI
Security Manager, you can fully manage your security.
