Key
Features
Model:
VIGI C230I (4mm)
Sensor: 1/2.8” Progressive Scan CMOS
Resolution:
Max. 3 MP (2304 × 1296) at 25/30 fps.
Lens:
4mm, Aperture: F2.0, IR Distance: 45 meters
Features:
PoE, IP67, IK10, DWDR, 3D DNR, Smart Detection
Specification
The
TP-Link VIGI C230I is a 3MP IR Dome Network Camera equipped with a 4mm fixed
focal lens.
Camera:
Sensor: 1/2.8” Progressive Scan CMOS
Shutter
Speed: 1/3 to 1/10000 seconds
Slow
Shutter: Supported
Minimum
Illumination: Color: 0.01 Lux; 0 Lux with IR
Day/Night
Mechanism: IR Cut Filter
Day/Night
Switch: Unified/Scheduled/Auto
Lens:
Type:
Fixed Focal Lens
Focal
Length: 4 mm
Aperture:
F2.0
Field
of View (FOV):
Horizontal:
82.8°
Vertical:
44.5°
Diagonal:
98.1°
Lens
Mount: M12
DORI
Distance:
Detect:
65 m (214 ft)
Observe:
27 m (89 ft)
Recognize:
13 m (43 ft)
Identify:
7 m (21 ft)
Angle
Adjustment (Manual):
Pan:
0° to 355°
Tilt:
0° to 75°
Illuminator:
IR
LED:
Quantity:
2
Range:
30 m
Wavelength:
850 nm
Illuminator
On/Off Control: Auto/Scheduled/Always on/Always off
Video:
Max.
Resolution: 2304 × 1296
Main
Stream:
Frame
Rate: 1 fps, 5 fps, 10 fps, 15 fps, 20 fps, 25 fps
Resolution
Options: 2304x1296, 2048x1280, 1920x1080, 1280x720
Note:
If the image rotation is set to 90° or 270°, the frame rate supports up to 20
fps.
Sub-Stream:
Frame
Rate: 1 fps, 5 fps, 10 fps, 15 fps, 20 fps, 25 fps
Resolution
Options: 704x576, 640x480, 352x288, 320x240
Alarm
and Event Management:
Smart
Events:
Intrusion
Detection
Line-Crossing
Detection
Region
Entering Detection
Region
Exiting Detection
Object
Abandoned/Removal Detection
Abnormal
Sound Detection
People
Detection
Vehicle
Detection
Basic
Events:
Motion
Detection (Enhanced with Human & Vehicle Classification for more accurate
alerts)
Video
Tampering Detection
Exception
(Illegal Login)
Alarm
Linkage: Message Push
Interfaces:
Network
Interface: 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
Power:
DC Power Port
Built-in
Microphone: Yes; captures audio within a 15-ft radius
General:
Operating
Temperature: -30–60 °C
Storage
Temperature: -40–60 °C
Operating
Humidity: 95% or less (non-condensing)
Storage
Humidity: 95% or less (non-condensing)
Dimensions
(H x W x D): 115 × 115 × 86 mm
Material:
Plastic
Weight:
Net:
0.27 kg
Gross:
0.45 kg
Power
Consumption:
12V
DC: Max 5W
PoE:
Class 0
Power
Supply: 12V DC ± 5%, 5.5mm Coaxial Power Plug; PoE (802.3af/at, class 0)
Vandal
Resistance: IK10
Protection:
IP67, IK10
Certifications:
CE/BSMI/VCCI/ONVIF
Video/Image:
Video
Compression:
Main
Stream: H.265+/H.265/H.264+/H.264
Sub-Stream:
H.265/H.264
Settings: Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR,
White Balance (adjustable via client software), Rotation (90
Warranty
Warranty:
1 Year
Description
The
TP-Link VIGI C230I Dome IP Camera has a 3 MP resolution, which is
more than enough to capture some finer details. allows for the more
precise separation of cars and people so that you can receive event
notifications. When someone enters an area you've designated, crosses a border,
blocks the camera, or takes away or abandons an object, you may monitor the
feeds and receive notifications. This VIGI dome camera is constructed robustly
to survive vandalism and hard settings with rain and dust for constant security
anywhere and anytime. It has a durable casing that is resistant to vandalism
and a waterproof design. Your cameras send compressed, clear video without
requiring additional bandwidth, which frees up storage space, lightens network
traffic, and lowers monitoring expenses without compromising image quality.
With the help of expert technologies like Smart IR, WDR, 3D DNR, and Night
Vision, VIGI can process videos to significantly increase their quality—a
crucial aspect of your monitoring. One RJ45 cable can carry data and power to
your PoE camera, making it easy to connect and power it. An adapter for
electricity is not required. The C230I has two distinct lens types to better
meet your security needs: a wide-angle lens for covering confined locations and
a higher millimeter lens for greater distances in open spaces. Take complete
charge of your security with these three administration techniques: VIGI
Security Manager, the VIGI app, and the NVR UI.
