Key
Features
Model:
VIGI C430I (4mm)
Sensor: 1/2.8” Progressive Scan CMOS
Features:
PoE, DWDR, 3D DNR, Smart Detection
Resolution:
Max. 3 MP (2304 × 1296) at 25/30 fps.
Lens:
4mm, Aperture: F2.0, IR Distance: 30 meters
Specification
The
TP-Link VIGI C430I is a 3MP IR Turret Network Camera designed for
high-definition surveillance.
Camera:
Sensor: 1/2.8” Progressive Scan CMOS
Shutter
Speed: 1/3 to 1/10000 seconds
Slow
Shutter: Supported
Aperture:
F2.0
Lens:
4 mm fixed focal length
Lens
Mount: M12
Minimum
Illumination: Color: 0.1 Lux; 0 Lux with IR
Day/Night
Mechanism: IR Cut Filter
Day/Night
Switch: Unified/Scheduled/Auto
Digital
Noise Reduction: 3D DNR
Wide
Dynamic Range (WDR): DWDR
IR
Working Distance: Up to 30 meters
Viewing
Angle: Horizontal: 82.5°, Vertical: 44.9°, Diagonal: 99.3°
Lens:
Type:
Fixed Focal Lens
Focal
Length: 4 mm
Aperture:
F2.0
Field
of View (FOV):
Horizontal:
82.5°
Vertical:
44.9°
Diagonal:
99.3°
Lens
Mount: M12
DORI
Distance:
Detect:
65 m (214 ft)
Observe:
27 m (89 ft)
Recognize:
13 m (43 ft)
Identify:
7 m (21 ft)
Angle
Adjustment (Manual):
Range:
Pan:
0° to 360°
Tilt:
0° to 85°
Rotate:
0° to 360°
Illuminator:
IR
LED Quantity: 1
Range:
30 meters
Wavelength:
850 nm
Illuminator
On/Off Control: Auto/Scheduled/Always on/Always off
Video:
Max.
Resolution: 2304 × 1296
Main
Stream Frame Rate: 1 fps to 25 fps
Main
Stream Resolutions: 2304×1296, 2048×1280, 1920×1080, 1280×720
Sub-Stream
Frame Rate: 1 fps to 25 fps
Sub-Stream
Resolutions: 704×576, 640×480, 352×288, 320×240
Bit
Rate Control: CBR, VBR
Video
Compression: Main Stream: H.265+/H.265/H.264+/H.264; Sub-Stream: H.265/H.264
H.264
Type: Main Profile/High Profile
H.264+:
Supported
H.265
Type: Main Profile
H.265+:
Supported
Video
Bit Rate: Main Stream: 256 Kbps to 4 Mbps; Sub-Stream: 64 Kbps to 512 Kbps
Image:
Settings: Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR,
White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client
Software, Rotation (90°/270°)
Enhancement: BLC/3D DNR/HLC/SmartIR
Wide
Dynamic Range: WDR
SNR:
≥ 52 dB
Parameters Switch: Yes
Privacy
Mask: Up to 4 Masks
ROI:
1 Region
OSD
Setting: Yes
Audio:
Audio
Communication: Not Applicable
Audio
Input: Not Applicable
Audio
Output: Not Applicable
Audio
Compression: Not Applicable
Audio
Sampling Rate: Not Applicable
Environment
Noise Filtering: Not Applicable
Audio
Bit Rate: Not Applicable
Network:
Protocol:
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP, UDP, SSL/TLS
ONVIF:
Yes
API:
ONVIF
Simultaneous
Live View: 3 Main Streams & 3 Sub-Streams
Client:
VIGI App, VIGI Security Manager, VIGI NVR, Web
Warranty
Warranty:
1 Year
Description
The VIGI
C430I Dome Camera has a 3 MP resolution, which is more than enough to
capture some of the finer details. allows for the more precise separation of
cars and people so that you can receive event notifications. When someone
enters an area you've designated, crosses a border, blocks the camera, or takes
away or abandons an object, you may monitor the feeds and receive
notifications. Your cameras send compressed, clear video without requiring
additional bandwidth, which frees up storage space, lightens network traffic,
and lowers monitoring expenses without compromising image quality. Professional
technologies from VIGI, such as Smart IR, WDR, 3D DNR, and Night Vision,
process videos to significantly increase their quality—a crucial aspect of your
surveillance. helps to monitor long and narrow regions and lets you switch the
visual aspect ratio from 16:9 to 9:16. One RJ45 cable can carry data and power
to your PoE camera, making it easy to connect and power it. An adapter for
electricity is not required. The C430I has two distinct lens types to better
meet your security demands, whether you need a wide-angle lens to cover
confined locations or a greater millimeter lens for longer distances in open
spaces. Using the NVR UI, VIGI app, and VIGI Security Manager, you can fully
manage your security. The cable of the TP-Link VIGI C430I 3MP Dome IP
Camera can be easily routed into a dropped ceiling or, to prevent
drilling, inserted through the side outlet of the camera.
