Brand: HAIER
Model No: HSU-12AquaCool
Capacity (BTU): 12000
EER: 2.96
Refrigerant: R32
Capacity (W): 3520
Model Name
Indoor: HSU-12AquaCool(FIX)(3D)(QB)
Outdoor: HSU-12KV24(FIX)
Capacity and Parameters
Type: Non-Inverter
Ton Range (TR): 1.0 Ton
Capacity(BTU): 12000
Rated Cooling Capacity (W): 3520
Rated Heating Capacity (W): /
Rated Power Input Cooling (W): 1210
Rated Power Input Heating (W): /
Max. Power input Cooling (W): 1400
Max. Power input Heating (W): /
Energy Effeciency Ratio (EER): 2.96
Coefficient of Performance (COP): /
Rated Running Current (A) Cooling: 5.2
Rated Running Current (A) Heating: /
Max.Running Current (A) Cooling: 6.5
Max.Running Current (A) Heating: /
Power supply (Ph,V,Hz): 1/230/50HZ
Air Circulation (m3/h): 650
Moisture Removal (10-3m3/h): /
Refrigerant Type: R32
Refrigerant Standard (Kg): 0.600
Refrigerant Pipe Liquid Side Diameter (mm): 6
Refrigerant Pipe Gas Side Diameter (mm): 9
Compressor Type: Rotary
Evaporator/Condenser: 100% 7mm Grooved Copper
Heat Exchangers: Golden Fin
Indoor
Indoor Net dimension (mm) W/D/H: 805*200*292
Indoor Package dimension (mm) W/D/H: 876*272*365
Indoor Net weight (kg): 9.5
Indoor Gross weight (kg): 11.5
Indoor Sound power level [dB(A)] Hi/Mid/Lo: 41/38/35
Outdoor
Outdoor Net dimension (mm) W/D/H: 800*280*553
Outdoor Package dimension (mm) W/D/H: 908*405*627
Outdoor Net weight (kg): 29.5
Outdoor Gross weight (kg): 32.5
Outdoor Sound power level [dB(A)] Hi/Mid/Lo/So:
52
Air Flow Direction
Up & Down: Auto
Left & Right: Auto
User Functions
Highly Efficient lonizer: Yes
Energy Saving: Yes
Dry Mode: Yes
Turbo Function: Yes
Auto Restart Function: Yes
Sleep Mode: Yes
Low Noise: Yes
Timer: Yes
Quick & Easy Installation: Yes
Child Lock: Yes
Warranty
Compressor (Yrs): 5
Spare Parts and Components (Yrs): 1
Service (Yrs): 1
