Function:
Cooling
Cooling Capacity (W): 14068
Compressor Type: Scroll (Fixed Speed)
Net
Weight (Indoor) (Kg): 40 ± 1
Gross
Weight (Indoor) (Kg):
47 ± 1
Net
Weight (Outdoor) (Kg): 83 ± 1
Gross
Weight (Outdoor) (Kg): 84 ± 1
Net
Weight (Indoor Front Panel) (Kg): No
Gross
Weight (Indoor Front Panel) (Kg): No
Basic Features
|
Function |
Cooling |
|
BTU/hr |
48000 |
|
Rated
Voltage |
380V-420V
~ 50Hz |
|
Rated
Input Power (W) |
4950 |
|
Rated
Current (A) |
7.6 |
|
Cooling
Capacity (W) |
14068 |
|
EER |
2.84 |
Cooling Features
|
Compressor
Type |
Scroll
(Fixed Speed) |
|
Refrigerant
Type |
R-410a |
|
Refrigerant
Amount (Kg) |
2.6 |
|
Operating
Range (Ambient Temperature) |
21˚C to
43˚C |
|
Condenser
Type |
Copper
Tube Condenser |
|
Indoor
Fin Type |
Slit
Fin |
|
Outdoor
Fin Type |
Slit
Fin |
|
Maximum
Pipe Length |
30m |
Operations
|
Turbo
Mode (Faster Cooling) |
No |
|
Turbo
Mode (Maximum Cooling) |
Yes |
|
Eco
Mode |
No |
|
Auto
Operation |
Yes |
|
Dry
Mode |
Yes |
|
Fan
Mode |
Yes |
|
Speed
Setting |
Yes (Auto,
High, Medium, Low) |
|
Auto
Restart |
Yes |
|
Comfort
Colling |
Yes |
|
Timer |
Yes |
|
Sleep |
Yes |
Air Deflection
|
Auto
UP-Down Swing |
Yes |
|
Auto
Left-Right Swing |
Manual |
Remote
|
Display
Type |
7
Segment LED |
|
Display
Back Light |
Yes |
|
Operation/Control |
Via IR
(Infrared Ray) |
|
Child
Lock |
Yes |
|
Temperature
Unit Change |
Yes (16℃ to 32℃) |
Dimensions
|
Indoor
Dimensions (mm) [L×W×H] |
Unit: 1600
x 690 x 235 |
|
Packing: 1680
x 770 x 325 |
|
|
Outdoor
Dimensions (mm) [L×W×H] |
Unit: 917
x 330 x 960 |
|
Packing:
1030 x 400 x 1000 |
|
|
Front
panel Unit Dimension (mm) [LxWxH] |
No |
Weights
|
Net
Weight (Indoor) (Kg) |
40 ±1 |
|
Gross
Weight (Indoor) (Kg) |
47 ± 1 |
|
Net
Weight (Outdoor) (Kg) |
83 ±1 |
|
Gross
Weight (Outdoor) (Kg) |
94 ±1 |
|
Net
Weight (Indoor Front Panel) (Kg) |
No |
|
Gross
Weight (Outdoor Front Panel) (Kg) |
No |
Guarantee/Warranty Information
Product Replacement Guarantee: 1 Year
(Note: if there are manufacturing faults in the heat
exchanger & compressor)
For Commercial UsageCompressor Guarantee: 5
YearsSpare Parts Support: 2 YearsAfter Sales Service: 1
Year (Free)
Terms & Conditions
1. This warranty does not cover the following cases -
i) The warranty will be invalid if the
product is misused, neglected, or rented on a commercial basis. The warranty
also will be invalid if repaired, replaced modified by unauthorized service
personnel.
ii) If the product serial
number/barcode is removed, altered, or duplicated, the warranty will be
invalid.
2. This warranty covers only manufacturing defects in
products & workmanship, subject to verification by company personnel.
3. Authority reserves the right to change, extend,
correct, stop or cancel the warranty period without any prior notice.
4. After sales free service will be applicable only at
authorized service points.
