Function:
Cooling
Cooling
Capacity (W): 3517
Compressor
Type: Rotary
(Inverter)
Net Weight (Indoor) (Kg): 11±0.5
Gross Weight (Indoor) (Kg): 13±0.5
Net Weight (Outdoor) (Kg): 28±1
Gross Weight (Outdoor) (Kg): 32.7±1
Basic
Features
|
Function |
Cooling |
|
BTU/hr |
12000 |
|
Rated
Voltage |
230V ~ 50Hz |
|
Rated Input
Power (W) |
1260 |
|
Rated
Current (A) |
5.6 |
|
Cooling
Capacity (W) |
3517 |
|
EER |
2.8 |
Heating &
Cooling Features
|
Compressor
Type |
Rotary
(Fixed Speed) |
|
Refrigerant
Type |
R-410a |
|
Refrigerant
Amount (kg) |
0.7 |
|
Operating
Range (Ambient Temperature) |
20˚C to
43˚C |
|
Evaporator
Fin Type |
Louvered
Fin |
|
Condenser
Type |
Copper Tube
Condenser |
|
Condenser
Fin Type |
Slit Fin |
|
Maximum
Pipe Length |
10m |
Operations
|
Turbo Mode
(Maximum Cooling) |
Yes |
|
ECO Mode
(Power Saving) |
No |
|
Dry
Mode |
Yes |
|
Fan Mood |
Yes |
|
Auto
Operation |
Yes |
|
Auto
Restart |
Yes |
|
Comfort
Cooling |
Yes |
|
Speed
Setting |
Yes (Auto,
High, Medium, Low) |
|
Timer |
Yes |
|
Sleep |
Yes |
Air
Deflection
|
Auto
UP-Down Swing |
Yes |
|
Auto
Left-Right Swing |
Yes |
Remote
|
Display
Type |
LCD |
|
Operation/Control |
Via IR
(Infrared Ray) |
|
Child Lock |
Yes |
|
Temperature
Unit Change |
Yes |
Dimensions
|
Indoor
Dimensions (mm) [L×W×H] |
Unit: 844 x
296 x 210 |
|
Packing:
910 x 365 x 285 |
|
|
Outdoor
Dimensions (mm) [L×W×H] |
Unit: 721 x
320 x 552 |
|
Packing:
825 x 365 x 630 |
Weights
|
Net Weight
(Indoor) (Kg) |
11±0.5 |
|
Gross
Weight (Indoor) (Kg) |
13±0.5 |
|
Net Weight
(Outdoor) (Kg) |
28±1 |
|
Gross
Weight (outdoor) (Kg) |
32.7±1 |
Guarantee/Warranty
Information
Product
Replacement Guarantee: 1 Year
(Note: if
there are manufacturing faults in the heat exchanger & compressor)
For
Residential UsageCompressor
Guarantee: 5 YearsSpare Parts Support: 3 YearsAfter
Sales Service: 1 Year (Free)
For
Commercial UsageCompressor
Guarantee: 5 YearsSpare Parts Support: 2 YearsAfter
Sales Service: 1 Year (Free)
Terms & Conditions
1. This
warranty does not cover the following cases -
i) The warranty will be invalid if the product is misused, neglected, or
rented on a commercial basis. The warranty also will be invalid if repaired,
replaced modified by unauthorized service personnel.
ii) If the product serial number/barcode is removed, altered, or
duplicated, the warranty will be invalid.
2. This
warranty covers only manufacturing defects in products & workmanship,
subject to verification by company personnel.
3.
Authority reserves the right to change, extend, correct, stop or cancel the
warranty period without any prior notice.
