Function:
Cooling
Cooling
Capacity (W): 5275
Compressor
Type: Rotary
(Inverter)
Net
Weight (Indoor) (Kg): 10.7 ± 0.5
Gross
Weight (Indoor) (Kg):
12.85 ± 0.5
Basic Features
|
Function |
Cooling |
|
BTU/hr |
12000 |
|
Rated
Voltage |
230V ~
50Hz |
|
Rated
Input Power (W) |
1120 |
|
Rated
Current (A) |
4.86 |
|
Cooling
Capacity (W) |
3517 |
|
EER |
3.14 |
|
Smart
Control |
Through
App |
Cooling Features
|
Compressor
Type |
Rotary
(Inverter) |
|
Refrigerant
Type |
R-32 |
|
Refrigerant
Amount (kg) |
0.42 |
|
Operating
Range (Ambient Temperature) |
20˚C to
52˚C |
|
Evaporator
Fin Type |
Louvered
Fin |
|
Condenser
Type |
Copper
Tube Condenser |
|
Condenser
Fin Type |
Louvered
Fin |
|
Maximum
Pipe Length |
10m |
Operations
|
Turbo
Mode (Maximum Cooling) |
Yes |
|
ECO
Mode (Power Saving) |
Yes |
|
Dry
Mode |
Yes |
|
Fan
Mood |
Yes |
|
Auto
Operation |
Yes |
|
Auto
Restart |
Yes |
|
Comfort
Colling |
Yes |
|
Speed
Setting |
Yes (Auto,
High, Medium, Low) |
|
Timer |
Yes |
|
Sleep |
Yes |
Air Deflection
|
Auto
UP-Down Swing |
Yes |
|
Auto
Left-Right Swing |
Yes |
Remote
|
Display
Type |
LCD |
|
Operation/Control |
Via IR
(Infrared Ray) |
|
Child
Lock |
Yes |
|
Temperature
Unit Change |
Yes
(16°C to 31°C) |
Dimensions
|
Indoor
Dimensions (mm) [L×W×H] |
Unit:
832 x 292 x 210 |
|
Packing:
910 x 365 x 285 |
|
|
Outdoor
Dimensions (mm) [L×W×H] |
Unit:
844 x 310 x 546 |
|
Packing:
900 x 372 x 610 |
WeightsOutdoor
|
Net
Weight (Indoor) (Kg) |
10.7 ±
0.5 |
|
Gross
Weight (Indoor) (Kg) |
12.85 ±
0.5 |
|
Net
Weight (Outdoor) (Kg) |
23 ± 1 |
|
Gross
Weight (outdoor) (Kg) |
27 ± 1 |
|
Guarantee/Warranty
Information |
|
|
Product
Replacement Guarantee: 1 Year (Note:
if there are manufacturing faults in the heat exchanger & compressor) |
|
|
For
Residential Usage |
Compressor
Guarantee: 10 Years |
|
Spare
Parts Support: 3 Years |
|
|
After
Sales Service: 1 Year (Free) |
|
|
For
Commercial Usage |
Compressor
Guarantee: 5 Years |
|
Spare
Parts Support: 2 Years |
|
|
After
Sales Service: 1 Year (Free) |
|
|
Terms
& Conditions |
|
|
1.
This warranty does not cover the following cases -
i) The warranty will be invalid if the product is misused,
neglected, or rented on a commercial basis. The warranty also will be invalid
if repaired, replaced modified by unauthorized service personnel.
ii) If the product serial number/barcode is removed, altered,
or duplicated, the warranty will be invalid. 2.
This warranty covers only manufacturing defects in products &
workmanship, subject to verification by company personnel. 3.
Authority reserves the right to change, extend, correct, stop or cancel the
warranty period without any prior notice. |
|
