Product Type

LED TV

TV System

PAL ; NTSC ; SECAM

Receiving Range

48.25MHz - 863.25 MHz

No of Channel (ATV)

99

Power Supply

AC 110V-240V 50/60Hz

Power Consumption (TV On)

48W

Power Consumption (STB)

< 0.5 W

Hardware Configuration :

CPU

CA35*4

GPU

G31MP2

CPU Frequency

1.8 GHz

GPU Frequency

800 MHz

DDR RAM Size

512 MB

eMMC Flash

4 GB (* Available storage will be less than the total memory due to storage of operating
              system and software pre-installed on the device.)

Software Configuration :

OS

Coocaalite (Coolita)

App Store

Yes

Screen Mirroring

CC Cast

YouTube

Yes

Browser

Yes

HDMI (CEC,ARC)

Yes

Panel Specification :

Backlight Unit

DLED

Aspect Ratio

16:9

Panel Size

610 mm

Display Resolution

1366 X 768

Brightness

240± 10 cd/m2 (typical)

Contrast Ratio

5000:1 (typical)

Response Time

8  ms (typical)

Viewing Angle

178° / 178°

Color

Black

Refresh Rate

60 Hz

Power Supply and Consumption:

Power Supply

AC 110V-240V 50/60Hz

Power Consumption (TV On)

45W

Power Consumption (STB)

< 0.5 W

Sound :

Audio Power Output

2 X 10 Watt

Sound Mode

User, Standard, Soccer, Movie, Music etc.

Sound Control

2 Ch Speaker System

Terminals :

Bottom Terminals:

RJ45 (LAN Port)

1

Optical Out

1

HDMI In

2

Earphone Out

1

Rf  In

1

Side Terminals:

AV In

2

USB 2.0

2

Device Media Format :

Audio

MP3; WAV; AC3


JPEG/BMP/PNG

Video

MP4; TS/TRP; MPG; MOV; DAT; FLV;3GPP

Dimensions & Weight :

TV with Stand (L × W × H)

565 mm x 155 mm x 385 mm

TV without Stand (L × W × H)

565 mm x 48 mm x 346 mm

TV Shipping dimensions (L × W × H)

600 mm × 140 mm × 445 mm

TV with Stand Weight

2.6  KG

TV without Stand Weight

2.58  KG

TV Shipping Weight

3.86  KG

Loading :

Shipping Qty (40HC)

1445 pcs (Approx.)

Shipping Qty (40GP)

1445 pcs (Approx.)

Shipping Qty (20GP)

705 pcs (Approx.)
