CPU

CA55*4

GPU

Mali-G31 MP2

CPU Frequency

MAX 1.45 GHz

GPU Frequency

550 MHz

DDR RAM Size

1GB

eMMC Flash

8 GB

Software Configuration :

OS

Android 11.0 (Android TV)

Google Play Store

Yes

Screen Mirroring

Chrome cast

Bluetooth Version

2.1+EDR/4.2/5.1

YouTube

Yes

Netflix

Yes

Amazon Prime

Yes

HDMI (CEC,ARC)

Yes

Panel Specification :

Backlight Unit

DLED

Aspect Ratio

16:9

Panel Size

813 mm

Display Resolution

1366 X 768

Brightness

250 cd/m2 (typical)

Contrast Ratio

3000:1 (typical)

Response Time

8 ms (typical)

Viewing Angle

178° / 178°

Color

Black

Frame Rate

60 Hz

Power Supply and Consumption :

Power Supply

AC 110V-240V 50/60Hz

Power Consumption (TV On)

45W

Power Consumption (STB)

< 0.5 W

TV System:

Video system

PAL/ SECAM/ NTSC

Sound system

BG/ D/ K/ I

Receiving Range

48.25MHz - 863.25 MHz

Receive Channel

99

Sound :

Audio Power Output

2 X 10 Watt

Sound Mode

User, Standard, Vivid, Sports, Movie, Music, News

Sound Control

2 Ch Speaker System

Terminals :

Bottom Terminals:

RJ45 (LAN Port)

1

Optical Out

1

HDMI In

3

AV In

1

Side Terminals:

RF In

1

USB 2.0 (FAT 32)

2

Device Media Format :

Audio

MP3; WAV;ACC;AC3


JPEG/BMP/PNG

Video

MP4; TS/TRP; MPG; MOV; DAT; FLV;3GPP

Dimensions & Weight :

TV with Stand (L × W × H)

730 mm x 77 mm x 475 mm

TV without Stand (L × W × H)

730 mm x 77 mm x 430 mm

TV Shipping dimensions (L × W × H)

805 mm x 135 mm x 510 mm

TV with Stand Weight

3.94

TV without Stand Weight

3.86

TV Shipping Weight

5.6

Loading :

Shipping Qty (40HC)

1200 Pcs (Approx.)

Shipping Qty (40GP)

952 Pcs (Approx.)

Shipping Qty (20GP)

448 Pcs (Approx.)
