Type

Direct Cool

Capacity:

Gross Volume

268 Liter.

Net Volume

254 Liter.

Net Weight

62 ± 2 Kg

Gross Weight

67 ± 2 Kg

Performance:

Climatic Type (SN, N, ST, T)

N~ST

Rated Voltage/ Hz

220 ~ 240/ 50

Compressor Input Power (Watt)

V 02.01-132
V 03.01-118
V 03.02-118
V 04.01-127

Compressor Type

V 02.01-RSCR
V 03.01-RSCR
V 03.02-RSCR
V 04.01-RSCR

Cooling Effect

Freezer Cabinet Less than -18℃
Refrigerator Cabinet 0℃ to +5℃

Energy Rating

5 star (BDS 1850:2012)

General Features:

Temperature Control (Electronic/ Mechanical)

Mechanical

Defrosting (Automatic/ Manual)

Manual

Reversible Door

No

Handle (Recessed/ Grip)

Recessed/ Grip

Lock

Yes

Refrigerant

R600a

Thermostat

RoHS Certified

Capillary

Copper

Polyurethane foam blowing agent

CycloPentane [Eco-friendly (100% CFC &
HCFC Free) Green Technology]

Recommended voltage stabilizer capacity

V 02.01-1000VA
V 03.01,V 03.02-Low Voltage(140~260V)
For V 03.01,V 03.02 - Wide Voltage Range (140Vac - 260Vac). Voltage stabilizer is not required. In case of voltages beyond this range, 1000VA is recommended.
V 04.01-Low Voltage (150~260V)
For V 04.01 - Wide Voltage Range (150Vac - 260Vac). Voltage stabilizer is not required. In case of voltages beyond this range, 1000VA is recommended.

Refrigerator Compartment:

Shelf (Material/ No.)

Wire/2

Door Pocket

GPPS/4

Interior Lamp

Yes

Vegetable Crisper

Yes

Vegetable Crisper Cover

Yes

Egg Tray

Yes

Freezer Compartment:

Shelf (Material/ No.)

Wire/3

Drawer

HIPS/5

Door Pocket

No

Interior Lamp

No

Net Dimensions:

Width/mm

555 mm

Depth/mm

630 mm

Height/mm

1800 mm

Packaging :

Width/mm

580 mm

Depth/mm

645 mm

Height/mm

1845 mm

Loading Capacity- 40HQ/ 40Ft/ 20Ft

97/ 72/ 36Warranty Information:

Residential Use:
- Replacement Guarantee: 1 Year (Condition Apply)
- Main Parts (Compressor): 12 Years

- Door: 3 Years *
- Spare Parts: 4 Years *
- After Sales Service:5 Years *

Commercial Use:
- Main Parts (Compressor): 4 Years

- Door: 1 Years *
- Spare Parts: 2 Years *
- After Sales Service: 2 Years *


Note:

This warranty does not cover the following cases:

1. Any damage due to accident, electrical fault, natural causes, negligence or improper installation.
2. Any damage or failure caused by unauthorized modification or alteration.
3. Products with original serial numbers that have been removed, distorted or cannot be readily recognized.

Authority keeps the right to change, extend, correct, stop or cancel the warranty period without any prior notice.

*This warranty covers only manufacturing defects in products & workmanship, subject to verification by company personnel.
