Cooling Features :
| Type | Direct Cool |
| Capacity : | |
| Gross Volume | 337 Ltr |
| Net Volume | 317 Ltr |
| Performance : | |
| Climate Type (SN, N, ST, T) | N~ST |
| Rated Operating Voltage and Frequency | 220-240V~ and 50Hz |
| Compressor Input Power (Watt) | V 0301- 118 |
| Compressor Type | RSCR |
| Cooling Effect | Freezer Cabinet Less than -180C Refrigerator Cabinet 00C to +50C |
| General features | |
| Temperature Control (Electronic/ Mechanical) | Mechanical |
| Defrosting (Automatic/ Manual) | Manual |
| Reversible Door | No |
| Handle (Recessed/Grip) | Recessed/Grip |
| Lock | Yes |
| Refrigerant | V 0301- R600a |
| Capillary | Copper |
| Polyurethane foam blowing agent | CycloPentene [Eco-friendly (100% CFC & HCFC Free) Green Technology] |
| Operating voltage | V 0301: Wide Voltage Design (150V-260V) N.B.: If out of voltage range(150V-260V), then suggested voltage stabilizer capacity is 2100VA. |
| Refrigerator Compartment : | |
| Shelf (Material/ No.) | Wire/3 |
| Door Basket | 4 |
| Interior Lamp | Yes |
| Vegetable Crisper Cover | Yes (Glass/ plastic) |
| Egg Tray or Pocket | Yes/2 |
| Can Storage Dispenser | No |
| Deodorizer | No |
| Freezer Compartment : | |
| Shelf (Material/No.) | Wire/2 |
| Drawer | No |
| Door Basket | 2 |
| Interior Lamp | No |
| Dimensions (Net) : | |
| Width/mm | 645 |
| Depth/mm | 670 |
| Height/mm | 1605 |
| Packing : | |
| Width/mm | 710 |
| Depth/mm | 710 |
| Height/mm | 1660 |
| Weight/Kg - Net/Packing | 61/ 69 ± 2 |
| Loading Capacity- 40HQ/ 40Ft/ 20Ft | 69/ 48/ 24 |
| Star rating (BDS 1850:2012) | 5 |
Warranty Information:
Residential Use:
- Replacement Guarantee: 1 Year (Condition Apply)
- Main Parts (Compressor): 12 Years
Residential Use:
- Replacement Guarantee: 1 Year (Condition Apply)
- Main Parts (Compressor): 12 Years
- Door: 3 Years *
- Spare Parts: 4 Years *
- After Sales Service:5 Years *
Commercial Use:
- Main Parts (Compressor): 4 Years
- Spare Parts: 4 Years *
- After Sales Service:5 Years *
Commercial Use:
- Main Parts (Compressor): 4 Years
- Door: 1 Years *
- Spare Parts: 2 Years *
- After Sales Service: 2 Years *
- Spare Parts: 2 Years *
- After Sales Service: 2 Years *
Note:
This warranty does not cover the following cases:
1. Any damage due to accident, electrical fault, natural causes, negligence or improper installation.2. Any damage or failure caused by unauthorized modification or alteration.
3. Products with original serial numbers that have been removed, distorted or cannot be readily recognized.
