Accessories (in package)	Connection copper pipe length: 3 m Communication cable length: ≥3.5 m External Length of Power cable length: ＞1.2m without Plug Insulating material: EPS Remote Control Battery Remote Control Holder Installation Kit Installation Kit - Wall Mounting Screw & Bolts Installation Kit - Additional Drainage Hose Additional Drainage Hose length: 2 m Installation Kit - Bandage Tape Installation Kit - Anti-Vibration Rubber Feet: option, 4 pcs Installation Kit - Wall Hole Plastic Cover
Technical Spacifications	T1 Cooling Capacity: 5275 W T1 Adjustable Cooling Capacity Range: 1880-5280 W Adjustable Compressor Frequency Range [Cooling]: 28-85 Hz T1 Energy Efficiency Cooling: 3.01 SEER/CSPF/AEER/Weight EER: 3.81 (SEER--BDS 1852:2022) Energy Level-Cooling: 3 Star (SRI) Annual Energy Consumption-Cooling: 2637 kWh/annual T1 Cooling Power Input: 1753 W Voltage/Frequency/Phase: 220-240V~/50Hz/1 T1 Cooling Running Current: 8.0 A Sound Pressure Level - Indoor Unit: 44/39/34/30 dB(A) Sound Pressure Level - Outdoor Unit: 54 dB(A) Indoor Air flow volume: 950/900/730/600 m³/h Outdoor Fan flowrate: 1900 m³/h Moisture removal: 2 L/H.r Max. elevation: 5 m Max. pipe length: 15 m Additional Gas Quantity: 20 g/m Rated Power Input-EN 60335: 2200 W Rated Current Input-EN 60335: 12 A Max. Suction Pressure: 1.6 MPa Max. Discharge Pressure: 4.15 MPa Max Allowable Pressure: 4.15 MPa Indoor unit Resistance Class: IPX0 Outdoor unit Resistance Class: IPX4 Ambient Working Temperature Range Cooling-Outdoor: 18-50 ℃ Compressor Type: Rotary Compressor Brand: GMCC Compressor Drive: Inverter Compressor Model: "Authorized Component (Performance) Component 1: Trademark: GMCC Type:KSN108D34UFZ Spec:R32" Invert Module - Rectifier Module: D25SB100 Invert Module - IPM Module: PSS20S92F6 Invert Module - DSP Module: SC32F58D128LB1G Indoor Unit Fan Motor: RPG35D-2 35W Indoor Unit Fan Motor Capacitor (uF): 2 Outdoor Unit Fan Motor: YKT-29-6-222 27W Outdoor Unit Fan Motor Capacitor (uF): 3 Evaporator Pipe Diameter and thickness (mm): Φ7, 0.22mm Number of U-Tube Evaporator: 16 Evaporator Number of rows and dimension (number/mm): 2-670x336x27.2 Evaporator FPI value (mm): 1.4 Evaporator Fin Type: Golden aluminium Evaporator Fin Coating: hydrophilic aluminium Condenser Pipe Diameter and thickness (mm): Φ7, 0.22mm Number of U-tube Condenser: 14 Condenser number of rows and dimension (number/mm): 1-713x499x21.65 Condenser FPI value (mm): 1.3 Condenser Fin Type: Golden aluminium Condenser Fin Coating: hydrophilic aluminium High Pressure Pipe Diameter (mm): 6.35 Low Pressure Pipe Diameter (mm): 12.7 Power Supply Cord (mm²): 31.5 Indoor & Outdoor Connection Cord (mm²): 41.5 Indoor Unit (WxHxD): 890x300x220 mm Outdoor Unit (WxHxD): 715x540x240 mm Indoor Unit Net Weight: 10.0 kg Outdoor Unit Net Weight: 24.5 kg Packed Indoor Unit (WxHxD): 960x365x300 mm Packed Outdoor Unit (WxHxD): 830x588x340 mm Indoor Unit Weight - Packed: 12.0 kg Outdoor Unit Weight - Packed: 30.5 kg 40'HQ Container Loading Quantity (with kit): 256 Sets 40'GP Container Loading Quantity (with kit): 230 Sets 20' Container Loading Quantity (with kit): 111 Sets
