Type

Direct Cool

Capacity :

Gross Volume

268 Ltr.

Net Volume

254 Ltr.

Net Weight

62 ± 2 Kg

Gross Weight

67 ± 2 Kg

Performance :

Climatic Type (SN, N, ST, T)

N~ST

Rated Voltage/ Hz

220 ~ 240/ 50

Compressor Input Power (Watt)

V 02.01-132
V 03.01-118
V 03.02-118
V 04.01-127

Compressor Type

V 02.01-RSCR
V 03.01-RSCR
V 03.02-RSCR
V 04.01-RSCR

Cooling Effect

Freezer Cabinet Less than -18℃
Refrigerator Cabinet 0℃ to +5℃

Energy Rating

5 star (BDS 1850:2012)

General Features :

Temperature Control (Electronic/ Mechanical)

Mechanical

Defrosting (Automatic/ Manual)

Manual

Reversible Door

No

Handle (Recessed/ Grip)

Recessed/ Grip

Lock

Yes

Refrigerant

R600a

Thermostat

RoHS Certified

Capillary

Copper

Polyurethane foam blowing agent

Cyclopentene [Eco-friendly (100% CFC &
HCFC Free) Green Technology]

Recommended voltage stabilizer capacity

V 02.01-1000VA
V 03.01,V 03.02-Low Voltage(140~260V)
For V 03.01,V 03.02 - Wide Voltage Range (140Vac - 260Vac). Voltage stabilizer is not required. In case of voltages beyond this range, 1000VA is recommended.
V 04.01-Low Voltage(150~260V)
For V 04.01 - Wide Voltage Range (150Vac - 260Vac). Voltage stabilizer is not required. In case of voltages beyond this range, 1000VA is recommended.

Refrigerator Compartment :

Shelf (Material/ No.)

Wire/2

Door Pocket

GPPS/4

Interior Lamp

Yes

Vegetable Crisper

Yes

Vegetable Crisper Cover

Yes

Egg Tray

Yes

Freezer Compartment :

Shelf (Material/ No.)

Wire/3

Drawer

HIPS/5

Door Pocket

No

Interior Lamp

No

Net Dimensions :

Width/mm

555 mm

Depth/mm

630 mm

Height/mm

1800 mm

Packaging :

Width/mm

580 mm

Depth/mm

645 mm

Height/mm

1845 mm

Loading Capacity- 40HQ/ 40Ft/ 20Ft

97/ 72/ 36
